Ferrite SMD Shielded Type

Wire wound SMD inductor characterized by low DC resistance, and high current handling capacities.

Product Number Dimensions(mm) Inductance Range(uH) Rdc Range(Ω) Rated Current(A)

MSCDRI-2D11LD

3.0x3.0x1.2 1.5~33 68m~1.0 0.22~0.9

MSCDRI-2D11HP

3.0x3.0x1.2 1.5~33 80m~1.52 0.25~1.35

MSCDRI-2D14S

3.0x3.0x1.55 1.5~100 63m~2.4 0.12~1.8

MSCDRI-2D18LD

3.0x3.0x2.0 2.2~47 41m~0.66 0.20~0.85

MSCDRI-2D18HP

3.0x3.0x2.0 1.5~15 44m~0.345 0.7~1.85

MSCDRI-3D14LD

3.8x3.8x1.5 1.2~47 38m~1.08 0.25~1.5

MSCDRI-3D14HP

3.8x3.8x1.5 1.5~22 76m~0.83 0.65~2.6

MSCDRI-3D16LD

3.8x3.8x1.8 1.2~560 33m~13 0.07~1.5

MSCDRI-3D16HP

3.8x3.8x1.8 1.0~560 48m~15 0.09~2.5

MSCDRI-3D16

3.8x3.8x1.6 2.2~220 72m~4.0 0.15~1.2

MSCDRI-4D18C

5.1x5.1x2.0 1.1~100 29m~1.51 0.25~2.4

MSCDRI-4D28C

5.1x5.1x3.0 1.1~100 22m~0.948 0.4~3.8

MSCDRI-4D18

4.7x4.7x2.0 1.0~220 45m~2.4 0.15~1.72

MSCDRI-4D28

4.7x4.7x3.0 1.0~180 23.6m~1.54 0.22~2.56

MSCDRI-5D18

5.7x5.7x2.0 4.1~100 57m~1.2 0.36~1.95

MSCDRI-5D28

5.7x5.7x3.0 1.0~180 12m~1.55 0.32~3.7

MSCDRI-6D28

6.7x6.7x3.0 1.2~100 14m~0.535 0.54~4.5

MSCDRI-6D38

6.7x6.7x4.0 1.0~330 10m~1.55 0.35~4.5

MSCDRI-8D28

8.0x8.0x3.0 2.5~100 15.6m~0.43 0.75~4.5

MSCDRI-8D43

8.0x8.0x4.5 1.0~120 12.2m~0.51 1.0~8.0

MSCDRI-103R

10x10.1x3.1 1.0~150 11m~0.871 0.84~8.0

MSCDRI-104R

10x10.1x4.1 1.0~470 6.5m~1.49 0.55~10.5

MSCDRI-105R

10x10.1x5.1 1.5~1000 5.8m~1.989 0.48~10.5

MSCDRI-63

5.9x6.2x3.2 1.0~560 17m~5.23 0.15~3.4

MSCDRI-64

5.9x6.2x5.0 3.3~1000 27m~9.26 0.14~3.0

MSCDRI-73

7.3x7.3x3.6 1.0~1500 18.5m~11.2 0.14~5.0

MSCDRI-74

7.3x7.3x4.6 0.33~1000 8.7m~6.0 0.18~8.5

MSCDRI-1040

10.3x10.3x4.0 1.0~330 11.5m~2.3 0.7~12

MSCDRI-124

12.0x12.0x5.0 3.0~330 15m~0.99 0.5~7.0

MSCDRI-125

12.0x12.0x6.0 2.4~1000 15m~1.53 0.4~6.5

MSCDRI-127

12.0x12.0x8.0 1.0~1000 7m~2.48 0.45~9.8

MSCDRI-1210

12.0x12.0x10.0 1.3~220 3.8m~0.257 1.6~21

MSCDRI-6020LC

6.3x6.2x2.0 1.0~47 17m~0.542 0.5~3.5

MSCDRI-6025LC

6.3x6.2x2.5 1.0~100 14m~0.80 0.27~5.07

MSCDRI-6030LC

6.3x6.2x3.0 1.0~150 14m~0.738 0.31~3.59

MSCDRI-6035LC

6.3x6.2x3.5 2.0~100 19m~0.477 0.45~3.0

MSCDRI-5020F

5.3x5.3x2.0 1.2~100 44m~1.5 0.23~2.15

MSCDRI-5030F

5.3x5.3x3.0 1.1~100 20m~0.801 0.43~3.87

MSCDRI-6025F

6.0x6.0x2.5 2.2~100 24.1m~0.5 0.33~1.7

MSCDRI-63F

6x6x2.8 4.7~22 28.4m~0.162 0.8~1.6

MSCDRI-7028F

7.0x7.0x2.8 3.3~47 28m~0.34 0.54~1.6

MSCDRI-73F

7x7x3.2 1.5~1000 18m~4.78 0.13~3.4

MSCDRI-75F

7x7x4.5 1.0~1000 11m~2.28 0.14~4.5

MSCDRI-105F

10x10x4.5 3.3~1500 16.1m~3.4 0.22~4.9

MSCDRI-125F

12.5x12.5x5.5 6.0~1500 16.4m~1.73 0.29~3.6

MSCDRI-126F

12.5x12.5x6.5 2.0~1000 11.7m~1.1 0.3~10

MSCDRI-127F

12.5x12.5x7.5 1.2~220 6.9m~0.258 1.3~13

MSCDRI-3010X

3.0x3.0x1.0 0.47~470 70m~3.2 0.7~2.3

MSCDRI-3012X

3.0x3.0x1.2 1.0~22 80m~1.2 0.4~1.8

MSCDRI-3015X

3.0x3.0x1.5 1.0~100 75m~3.4 0.23~2.0

MSCDRI-4012X

4.0x4.0x1.2 0.33~15 23m~0.55 0.60~5.6

MSCDRI-4018X

4.0x4.0x1.8 0.56~1500 30m~30.0 0.08~4.8

MSCDRI-4020X

4.0x4.0x2.0 1.8~560 51m~6.6 0.12~1.97

MSCDRI-4025X

4.0x4.0x2.5 4.7~100 75m~2.5 0.25~1.6

MSCDRI-4030X

4.0x4.0x3.0 1.0~1000 20m~9.0 0.12~2.8

MSCDRI-5010X

5.0x5.0x1.0 0.33~560 30m~15.7 85m~3.5

MSCDRI-5015X

5.0x5.0x1.5 1.0~680 50m~10.6 0.10~3.5

MSCDRI-5020X

5.0x5.0x2.0 0.3~220 8.75m~3.3 0.26~6.0

MSCDRI-5025X

5.0x5.0x2.5 3.3~220 60m~1.8 0.20~2.3

MSCDRI-5030X

5.0x5.0x3.0 1.2~330 40m~1.8 0.17~3.5

MSCDRI-6012X

6.0x6.0x1.2 2.2~10 70m~0.24 1.0~2.3

MSCDRI-6015X

6.0x6.0x1.5 3.0~6.8 65m~0.13 1.6~2.2

MSCDRI-6020X

6.0x6.0x2.0 1.3~100 30.5~1.2 0.5~3.2

MSCDRI-6025X

6.0x6.0x2.5 1.0~47 35m~0.42 0.98~5.5

MSCDRI-6030X

6.0x6.0x3.0 1.0~47 13.85~0.30 1.1~4.2

MNR-3010

3.0x3.0x1.0 1.0~22 65m~1.03 0.35~1.3

MNR-3012

3.0x3.0x1.2 1.0~47 50m~1.45 0.25~1.5

MNR-3015

3.0x3.0x1.5 1.0~22 30m~0.52 0.47~2.1

MNR-4010

4.0x4.0x1.0 4.7~10 0.21~0.38 0.56~0.9

MNR-4018

4.0x4.0x1.8 1.0~22 30m~0.36 0.8~4.0

MNR-4026

4.0x4.0x2.6 3.5~6.6 50m~65m 1.5~1.7

MNR-6012

6.0x6.0x1.2 3.3~10 90m~0.235 1.0~1.8

MNR-6020

6.0x6.0x2.0 1.5~10 26m~0.125 1.7~4.0

MNR-6028

6.0x6.0x2.9 0.9~220 13m~1.3 0.45~6.6

MNR-6045

6.0x6.0x4.5 1.0~100 14m~0.50 0.8~8.5

MNR-8040

8.0x8.0x4.2 0.9~100 7.8m~0.377 1.0~7.8

MSCDRB-0905

13.5x9.5x5.2 0.47~220 10m~2.0 0.5~7.5

MSCDRB-1507

18.8x15.5x7.5 1.0~1000 16m~2.01 0.80~18

MSPM-3012

3.0x3.0x1.2 0.3~3.3 0.035~0.2 1.6~5

MSPM-4012

4.0x4.0x1.2 4.7~10 0.3~0.58 0.8~1.2

MSPM-4018

4.0x4.0x1.8 1.0~10 0.035~0.23 2.6~7

MSPM-4020

4.0x4.0x2.0 1.0~10 0.026~0.216 2.8~8.7

MSPM-6028

6.0x6.0x2.8 1.0~2.2 0.0216~0.0336 11~14
